Designed using the highest quality materials and components to provide the user with colder product temperatures, lower utility costs and exceptional food safety. High capacity, factory balanced refrigeration system that maintains -10F (-23.3C) temperatures. Ideal for both frozen foods and ice cream. Stainless exterior and aluminum side walls & back with stainless steel floor and ceiling. Three (3) Heavy duty, chrome plated, wire shelves per section. Positive seal self-closing doors with 120 stay open feature. Lifetime guaranteed door hinges. Lifetime guaranteed heavy duty all metal working door handles. Entire cabinet structure and solid door are foamed-in-place using Ecomate. A high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
| Model | STA3F-3S-HC |
| Door Count | 3 |
| Shelf Count | 9 |
| Weight (lbs) | 920 |
| Width (Imperial) | 77-3/4 |
| Depth (Imperial) | 33-3/4 |
| Height (Imperial) | 77-3/4 |
| Cord Length (Imperial) | 9 ft |
| Amps | 8.3 |
| Voltage | 208/230/60 |
| NEMA Configuration | 5-15P |
Factory engineered, self-contained, capillary tube system using environmentally friendly (CFC free) R404A refrigerant. High capacity, factory balanced refrigeration system that maintains -10°F (-23.3°C) temperatures. Ideal for both frozen foods and ice cream. State of the art, electronically commutated evaporator and condenser fan motors. ECM motors operate at higher peak efficiencies and move a more consistent volume of air which produces less heat, reduces energy consumption and provides greater motor reliability. Top mounted refrigeration system with evaporator positioned out of food zone.
Insulation - entire cabinet structure and solid door are foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
Lifetime guaranteed bolt style door locks. Lifetime guaranteed heavy duty all metal working door handles. Positive seal self-closing doors with 120° stay open feature. Lifetime guaranteed external cam lift door hinges, four (4) per door section. Magnetic door gaskets of one piece construction, removable without tools for ease of cleaning.
Three (3) heavy duty, chrome plated, wire shelves per section.
LED interior lighting, safety shielded.
Exterior digital temperature display, available with either °F or °C. Evaporator epoxy coated to eliminate the potential of corrosion. Curb mounting ready. NSF/ANSI Standard 7 compliant for open food product.
Unit completely pre-wired at factory and ready for final connection to a 208-230V / 60 Hz single phase, 15 amp dedicated outlet. Cord and plug set included.
